Hybrid Solar Inverter Performance

  • High battery voltage, higher efficiency
  • Intelligent working modes
  • Stronger UPS
  • Easy to use with battery
  • IP65, indoor & outdoor use
  • Free monitoring & remote upgrade
Solar Hybrid Inverter
  • Advanced Parallel, up to 60kW
  • Plug & Play, seamless switching under 10ms

Hybrid Solar Inverter Efficiency

96.5%

Europe Efficiency

97.5%

Max Efficiency

96.6%

Battery working efficiency

99.0%

MPPT Efficiency

Off Grid Solar Inverter Application

System Connection

A newly designed solar and energy storage best off grid inverter, capable to install in on-grid solar, off-grid solar and back-up systems. LXP Hybrid enables a programmable and scheduled smart solar energy storage system to help increase your solar energy self-consumption rate, protect your home appliances from grid shortage, and balance your energy usage strategy to save energy bill.

hybrid inverter

Off Grid Solar Inverter Working Modes

LXP hybrid inverters support variable working modes

Self consumption mode: Solar power will be used to take house load first, the left solar power will be used to charge the battery, after battery charged, the solar power can feed into grid.

Force charge and discharge mode: Off Grid Solar Inverter will charge or discharge battery according to the time users set.

Charge first mode: Solar power will used to charge battery first, then take family load and at last feed into grid. The best off grid inverter mode is used in the area where grid power supply is not stable

Parallel Connection

The LXP off grid solar inverter MG series support parallel connection function. Which means users can extend their off grid power very easily. Due to the advanced control method, there are some advantages for the parallel system:

  1. As more as 9 inverters can be connected
  2. There is no requirement for same length of cable connection
  3. Users can connect all inverters to a big battery bank or connect to different battery group
