Solar Hybrid Inverter Series

Intelligent Working Modes

Self consumption mode for high tariff areas

Charge priority mode for areas where grid power is unstable

Force charge and discharge mode for areas where tariff varies by time



Hybrid Inverter page 2

Easy to Use With Battery

Remote upgrade BMS firmware

Wide range of compatible battery brands

Wake up lithium battery from sleep mode

Essential info uploaded to lUX server for quick ESS diagnosis



Advanced Parallel

Up to 10 units parallel expandable to 120kW

Single phase and unbalanced three phase paralleling



Smart EPS

Plug&Play,seamless switching under 10ms

Sufficient backup power for emergency use



Key Features

Light,fast&easy installation

Free and handy monitoring on mobile&PC

Multi phases output on different hybrid models

Generator interface available



How solar hybrid inverter Works

Solar Hybrid Inverter System Connection

A newly designed solar and energy storage hybrid solar inverter, capable to install in on-grid solar, off-grid solar and back-up systems. LXP Hybrid enables a programmable and scheduled smart solar energy storage system to help increase your solar energy self-consumption rate. The hybrid inverter can protect your home appliances from grid shortage, and balance your energy usage strategy to save energy bill.

Solar Hybrid Inverter Parallel Connection

Paralleling LXP inverters in one phase to extend the single phase system capacity for either hybrid or AC coupled energy storage applications. Paralleling LXP inverters (single phase inverters) to build a three phase system for either hybrid or AC coupled energy storage applications. Smart paralleling algorithm enable multiple configurable working modes under on-grid, off-grid or micro grid applications.

Solar Hybrid Inverter Self Consumption

Under self consumption mode the energy generated by PV will be mainly used by local loads, and rest will be stored in the battery,excessive power will be fed back into the grid. This is the default mode which will increase the self consumption rate and reduce the energy bill significantly.

Force Hybrid Inverter Time Use

Force hybrid inverter charger time use mode, where there is a big difference tariff times. This solar hybrid inverter mode suits for situation where the price difference of energy is big. User can set the charging and discharging time and priority of energy use under Force Time Use mode. The user can also choose whether to charge the battery using grid power if the regulations permitted.
